This is
the new Mono Pico Compressor featuring balanced I/O, Peak and RMS
timings, switchable Hard and Soft Knee, Auto Attack-Release and Analog
GR meter drivers. More info |
|
We've
added a switch board for the Mono Pico Compressor to make building
easier.Four F2 and one F4 switch brought
out to a ten way pattern permit simple board-to-board connection. |
|
|
The
Stereo Edition Pico Compressor with True Power Summing provides
rock-stable stereo imaging and smooth, natural-sounding compression.
More info |
|
|
This
balanced I/O board mounts four 1/4" three conductor Neutrik P/N
NMJ6HFD2
connectors. |
|
|
A
general-purpose power supply based on the LM317/LM337 powers the Pico
Compressor. Construction
info here... |
|
|
For gain reduction we
offer a 10 segment meter featuring the LM3914. More
info Price: $6.50 US plus shipping |
|
|
For precision gain
reduction metering we offer this 20 segment meter featuring the
LM3914. Construction
info here ... Price: $8.95 US plus shipping |
|
|
Need to mount an F2 or F4
Switch to a panel? Try this little baby. Price: $3.95 US plus shipping |
|
|
Mono Pico Compressor
basic kit with circuit board and THAT ICs. Choose between the 10 LED
(shown) or 20 LED meter. Price with 10 segment meter: $39.95 US Price with 20 segment meter: $41.95 US Price does not include shipping |
|
|
Stereo Pico
Compressor basic kit with circuit board and THAT ICs. Choose between the
10 LED (shown) or 20 LED meter. Price with 10 segment meter: $69.95 US Price with 20 segment meter: $71.95 US Price does not include shipping |
|
|
Find documentation here. Schematics, bill of materials, photographs and more. | |
|
Join the Pico Compressor Forum. Talk with the designer and other Pico Compressor builders. | |
|
